The Data Center of the Future Is All-flash. Will the Last HDD Seller Please Turn Out the Lights?

By 2028, practically no new all-hard disk drive (HDD) storage systems will be sold for enterprise data center computing. That’s the prediction made by Pure Storage in a new white paper, “The All-flash Data Center Is Imminent,” which shows a clear and consistent decline in HDD shipments since their high more than a decade ago.

As of 2019, up to 80% of primary storage workloads were handled by all-flash arrays (AFAs), emphasizing the importance of high-performance storage solutions. Meanwhile, HDDs were largely relegated to secondary workloads, where factors like capacity and cost took precedence over speed. Despite this shift, HDDs still accounted for approximately 90% of the total stored enterprise data, underscoring their significant presence in the storage landscape.

In the era of AI, data usage is skyrocketing at an unprecedented rate, with its appetite for data showing no signs of slowing down. However, amid the demand for even more capacity, crucial considerations of efficiency and sustainability are now coming to the forefront. Once the king of capacity, the limitations of HDD in these areas are now becoming glaringly apparent as it struggles to meet the escalating demands placed upon it.al considerations of efficiency and sustainability are now coming to the forefront. Once the king of capacity, the limitations of HDD in these areas are now becoming glaringly apparent as it struggles to meet the escalating demands placed upon it.

Data Center Capacity: Direct and to the Point

IIt’s a different story for flash. Or more specifically, DirectFlash® technology from Pure Storage, rather than commodity off-the-shelf solid-state disks (SSDs).

With the introduction of quad-level cell (QLC) NAND and DirectFlash technology from Pure Storage, flash can now replace HDDs for capacity- and price-sensitive workloads at costs comparable to all-HDD systems (or even lower for larger systems). For the same capacity, Pure Storage systems are far denser (smaller) and more efficient than those built around both HDDs and SSDs.

“By delivering a more reliable, more consistent platform that consumes less space, power, and cooling resources, Pure Storage’s all-flash storage lowers operational spend, reduces the need for additional administrative resources, and helps shrink your data center footprint. This results in up to 40% lower TCO over six years, in contrast to comparable, disk-based systems.” –  Top Five Ways to Save Costs With a Consistent Data Storage Platform ebook

In fact, Pure Storage® DirectFlash Modules (DFMs) have up to six times larger capacities than the HDDs that would actually be deployed by enterprises in a production system, at the same comparable cost. They’re up to 10 times more efficient in terms of energy and power consumption and have up to 20 times more reliability.

By migrating to flash, especially DFMs, you save labor, rack space, and power usage—which translates to financial savings and better scalability—as well as better sustainability.

The Knock-on Effects of Size vs. Capacity

Let’s take a quick look at some of the factors that directly affect system sizing and the impact it can have long-term (which you can also find in depth in our new white paper). A simple example is a side-by-side comparison using the same capacity (4,096TB).  Taking HDD first with a 12TB HDD size (which is standard across many enterprises), you would need six times more physical drives than the comparable Pure Storage DFM system (75TB).

Now consider that during normal read/write operations, a single 75TB DFM draws roughly 10 watts, while those six 12TB HDDs will be drawing roughly 60 watts (6 x 10.1 watts). Add on the supporting infrastructure for those additional HDDs too—more controllers, more fans, more cables, more maintenance, more storage infrastructure, more complexity, more rack and floor space—which of course also all cost more to buy and run, and HDDs just don’t carry their weight.

Storage managers know that it is effective capacity, rather than raw capacity, that determines how much data can be stored. Disk vendors typically recommend not filling their devices more than 60%-80% full, because to do more can put both performance and data integrity at risk. And with off-the-shelf SSDs, which were designed to mimic HDDs, you are subject to similar constraints. Meanwhile, in a DFM and its marriage of hardware and software to directly manage the media, no such constraints exist—making the most of your effective capacity, space, and energy.shelf SSDs, which were designed to mimic HDDs, you are subject to similar constraints. Meanwhile, in a DFM and its marriage of hardware and software to directly manage the media, no such constraints exist—making the most of your effective capacity, space, and energy.

Is the same cost as HDD, and better than SSD, really true?

Efficiency is the cornerstone of cost management, considering that the total cost of ownership (TCO) of a system encompasses not only the initial purchase price but also the continuous expenses related to maintenance and support. Historically, HDDs might have been the economical option for high-capacity workloads. However, the decline in NAND costs, coupled with access to advanced flash capabilities and significant reductions in operational efforts, has substantially lowered both initial acquisition and ongoing management expenses.

Simultaneously, companies such as Pure Storage are developing specialized solutions to optimize high-capacity applications previously dominated by HDD technology, such as data repositories. Take, for instance, the newly introduced Pure//E™ Family. This innovative solution boasts 84% fewer storage devices than its all-HDD counterpart and 80% fewer than an equivalent all-flash array utilizing commodity off-the-shelf SSDs (COTS SSDs) for the same capacity. It exemplifies the trend of future-proofing data storage to reduce the overall costs of HDD and COTS SSDs while exceeding capacity and overall storage needs.

______________________________________________________________________

The comparisons above are based on the 75TB DFMs currently shipped by Pure Storage. Pure Storage DFMs are already up to 10 times more efficient in terms of energy and floor space consumption than HDDs today. But by the end of 2024, Pure Storage will be shipping 150TB DFMs, and 300TB by 2026. This massive density difference, together with the benefits of the Purity Operating System, shows clear advantages of DFMs over both HDDs and COTS SSDs. An all-flash data center is simply the logical step for any enterprise coming up on a technology refresh.

¹Statista, 2023 (https://www.statista.com/statistics/398951/global-shipment-figures-for-hard-disk-drives/)
